Veolia MK-5 EDI Module (Previously E-CELL-3X) For Semiconductor Industries

Thông tin chi tiết sản phẩm:

Nguồn gốc:	Trung Quốc
Hàng hiệu:	VEOLIA
Chứng nhận:	CE
Số mô hình:	MK-5 (trước đó là CELL-3X)
Tài liệu:	Veolia EDI catalog.pdf

Thanh toán:

Số lượng đặt hàng tối thiểu:	1 PC
Giá bán:	Có thể đàm phán
chi tiết đóng gói:	Đóng gói xuất khẩu tiêu chuẩn
Thời gian giao hàng:	5- 8 ngày làm việc
Điều khoản thanh toán:	T/T, Liên minh phương Tây
Khả năng cung cấp:	60000 đơn vị mỗi tháng

Tiếp xúc

Tất cả sản phẩm

Hộp phân phối ánh sáng (43)

Hộp phân phối điện (33)

Hộp phân phối thời tiết (48)

Hộp bao vây sợi thủy tinh (60)

Công tắc chuyển tự động ATS (68)

Các mô-đun EDI (160)

Các mô-đun màng siêu lọc (76)

Máy cắt công nghiệp (85)

hệ thống pv năng lượng mặt trời (72)

Trạm sạc EV điện (21)

Rơle thời gian mô-đun (12)

Rơle điều khiển tự động (64)

Biến áp điều chỉnh (16)

Bong bóng chiếu sáng phim (144)

Ánh sáng mặt trăng (145)

Bóng bay LED chân máy (122)

Tháp bơm hơi (76)

Phụ kiện khối đầu cuối (6)

Chi tiết sản phẩm

Chênh lệch áp suất tối thiểu MK-5 giữa ổ cắm pha loãng và đầu vào cô đặc (BAR):	0,34	MK-5 Inlet/Outlet Standard áp suất giảm (Bar):	1.4-2.8
Áp suất đầu vào MK-5 (Bar):	Phản đối: 4.1-6.9 Đồng hiện tại: 3.1-6.9	MK-5 Amperage (ADC):	0-5.2
Điện áp MK-5 (VDC):	0-400	Phục hồi MK-5:	lên đến 97%
Sản xuất nước được thiết kế (M3 /giờ):	4.0-6.4	Dòng chảy danh nghĩa:	5,0 m3/h (22 gpm)
Ứng dụng MK-5:	Lò hơi cho nước ăn trong các nhà máy điện
Làm nổi bật:	Máy bán dẫn của Veolia MK-5 EDI module , Mô-đun EDI cho ngành công nghiệp bán dẫn , Mô-đun EDI của Veolia với bảo hành

Veolia MK-5 EDI Module (Previously E-CELL-3X) For Semiconductor Industries

The Veolia E-Cell MK-5 Electrodeionization (EDI) Module is designed for continuous, chemical-free production of high-purity water, delivering flows up to 5 m³/h (22 GPM) with resistivity ≥16 MΩ·cm and silica removal to ≤5 ppb. Ideal for boiler feedwater in power plants and ultrapure water applications in semiconductors, microelectronics, and pharmaceuticals, it operates at up to 97% recovery without acid/caustic regeneration. The module features a compact design (30x61x72 cm), hot-water sanitization capability, and compliance with CE, RoHS, and ISO 9001/14001 standards. Its robust construction ensures low maintenance and stable performance under varying feedwater conditions, supported by Veolia’s global technical expertise

Product Specifications

Attribute	Value
Minimum pressure difference between dilute outlet and concentrate inlet (bar)	0.34
Dilute inlet/outlet standard pressure drop (bar)	1.4-2.8
Inlet pressure (bar)	Counter-current: 4.1-6.9 Co-current: 3.1-6.9
Amperage (ADC)	0-5.2
Voltage (VDC)	0-400
Recovery	up to 97%
Designed water production (m3/hr)	4.0-6.4
Nominal Flow	5.0 m3/h (22 gpm)
MK-5 Application	Boiler Feedwater In Power Plants

Veolia EDI Technology - Advanced Electrodeionization for High-Purity Water

Veolia's E-Cell ® EDI (Electrodeionization) technology represents the gold standard in continuous demineralization, offering a chemical-free, high-efficiency alternative to traditional mixed-bed ion exchange. Designed for industries requiring ultra-pure water, Veolia EDI stacks combine ion-exchange resins and selective membranes with direct current to remove contaminants—including silica and boron—without regeneration chemicals.

Key Advantages:

Zero Chemical Regeneration - Eliminates acid/caustic handling, reducing operational costs and safety risks.
Consistent High Purity - Produces water with > 16 MΩ*cm resistivity and < 5 ppb silica, meeting stringent standards for semiconductor, pharmaceutical, and power industries.
Energy-Efficient Design - Patented resin configuration and counter-current operation minimize power consumption and scaling risks.
Modular & Scalable - Available in MK-3, MK-5, and MK-9 stacks, supporting flows from 1.6 to 10 m³/h with up to 97% recovery.
Validated Reliability - CE, FDA, and Halal certified, manufactured in ISO 9001/14001 facilities with 85 °C hot-water sanitization options (PharmHT series).

Global Applications:

Microelectronics: Ultrapure rinse water for semiconductor fabrication.
Pharmaceutical: USP/EP-compliant purified water.
Power Generation: High-purity boiler feedwater.
Industrial Processes: Steel, chemical, and LNG plant demineralization.

Backed by Veolia's performance guarantees and global technical support, E-Cell EDI delivers sustainable, low-maintenance pure water solutions.

GE, Suez, and Veolia EDI Modules (all the same product: Veolia EDI Module)

Typical Applications

The water produced by the E-Cell-3X reliably meets today's most demanding ultrapure water applications, including but not limited to:

Ultrapure water for rinsing semiconductor chips, solar panels, and other microelectronic devices.
Demineralized feed water for high-pressure boilers in power plants and other heavy industrial sites.
Ultrapure water for green hydrogen generation in electrolyzers.

To simplify design and enhance your confidence in EDI applications, we offer E-Cell performance predictions and guarantees, which are available through Winflows* software or by contacting us.

Technical Specifications

Parameter	Value
Brand	Veolia EDI
Exchangeable ppm	65.0
Inlet Pressure bar	6.9
Inlet Pressure psi	100
Type of Stack	E-Cell 3X
Max Temperature °C	40
Max Temperature °F	104
Pressure drop bar	1,4-2,8
Pressure drop psi	20-40
Recovery %	up to 97 %
Flow m3/h	2,3-6,4
Flow rate gpm/ft2	10-28
Power voltage V	0-400 VDC
Shipping Weight kg	165
Shipping Weight lbs	364
Application	Ultrapure water, Boiler feed water

E-Cell-3X Stack Specifications

Parameter	Value
Nominal Flow	5.0 m3/h (22 gpm)
Flow Rate Range	2.3-6.4 m3/h (10-28 gpm)
Shipping Weight	165 kg (364 lbs)
Dimensions (width x height x depth)	30 cm x 61 cm x 72cm 12'' x 24" x 29"

Product Water Quality

Parameter	Value
Resistivity	≥ 16 MOhm-cm
Sodium	≤ 3 ppb
Silica (SiO2)	As low as 5 ppb
Boron	As low as 0.08 ppb

Note 1: Actual performance may vary based on site conditions. Refer to Winflows Prediction Software to verify expected product water quality.

Typical Removal Efficiencies

Parameter	Efficiency
Sodium	≥ 99.9% removal
Silica (SiO2)	Up to 99% removal
Boron	Up to 96% removal

Operating Parameters

Parameter	Value
Recovery	Up to 97%
Voltage	0-400 VDC
Amperage	0-5.2 ADC
Inlet Pressure Note 2	≤ 6.9 bar (100 psi)
Pressure Drop Note 3	1.4-2.8 bar (20-40 psi)

Note 2: Inlet pressure is determined by downstream pressure requirements for product and concentrate streams, choice of countercurrent or cocurrent operation, and stack pressure drop.

Note 3: At nominal flow and 25°C. Refer to Winflows Prediction Software to verify design conditions.

Feed Water Specifications

Parameter	Value
Total Exchangeable Anions (TEA as CaCO3) Note 5	≤ 65 ppm
Conductivity Equivalent	≤ 112 μS/cm
Temperature	4.4-40˚C (40-104˚F)
Total Hardness (as CaCO3) Note 6	≤ 1.0 ppm
Silica (SiO2) Note 7	≤ 1.0 ppm
Total Organic Carbon (TOC as C)	≤ 0.5 ppm
Total Chlorine	≤ 0.05 ppm
Fe, Mn, H2S	≤ 0.01 ppm
Boron Note 8	≤ 1.0 ppm
pH	4 to 11
Oil & Grease	None detectable
Particulate Note 9	RO permeate
Oxidizing Agents	None detectable
Color Note 10	≤ 5 APHA

Note 4: Refer to Winflows Prediction Software and the E-Cell Stack Operating Manual to verify feedwater specifications at design conditions.

Note 5: TEA (ppm as CaCO3) - Total Exchangeable Anions, this represents the concentration of all anions in the feedwater, including contributions from OH-, CO2 and SiO2. Winflows must be used to confirm that the feedwater TEA is acceptable at the given application operating conditions. Tabulated values are given at minimum flow and maximum temperature.

Note 6: The 1.0 ppm feedwater hardness limit as CaCO3 is for standard countercurrent operation only. Under co-current operation, the allowable feed water hardness is reduced to 0.1 ppm as CaCO3.

Note 7: At rates above nominal flow, the allowable silica limit is reduced. When feed water hardness exceeds 0.5 ppm as CaCO3, the allowable silica limit is reduced to 0.5 ppm.

Note 8: When a silica guarantee requirement exists or a resistivity guarantee requirement is above 10 MOhm-cm, the boron feed level is limited to 0.3 ppm as B, as higher boron levels may affect performance. In the absence of these requirements, the limit is 1.0 ppm boron.

Note 9: Reverse Osmosis (RO) or Equivalent Feed Water: RO provides feed water to the EDI that is essentially free of particulate matter, colloidal materials, and high molecular weight organic matter that could foul the ion exchange media. Because the EDI stack contains packed beds of ion exchange media that cannot be backwashed/fluidized to remove particulate matter, the quality of the RO permeate needs to be specified. Systems with an open system between the RO system (or other source) and the E-Cell (e.g., storage tank, decarbonator) must have a filter installed immediately before the E-Cell to protect the E-Cell from contamination by particulate matter. Generally, a 5µm absolute filter or 1µm nominal filter is acceptable.

Note 10: APHA - Color standard/scale named after the American Public Health Association and defined by ASTM.

Veolia E-Cell EDI Stack Models

E-Cell EDI Stack	Nominal Stack Flow Rate	Typical New-Build Applications
MK-9	8.0 m3/h (35 gpm)	Ultrapure water for solar photovoltaic and green hydrogen Boiler feedwater in power plants and other heavy industrial sites
MK-5	5.0 m3/h (22 gpm)	Ultrapure water for semiconductor, flat panel display, solar photovoltaic and other microelectronics Boiler feedwater in power plants and other heavy industrial sites
MK-3	3.4 m3/h (15 gpm)	Ultrapure water for semiconductor, flat panel display, solar photovoltaic and other microelectronics Boiler feedwater in power plants and other heavy industrial sites
MK-3PharmHT	3.4 m3/h (15 gpm)	High purity water compliant with United States Pharmacopeia (USP) and European Pharmacopeia (EP) standards for pharmaceutical and laboratory water injection
MK-3MiniHT	1.14 m3/h (5 gpm)	Pharmaceutical and laboratory purified water injection compliant with USP and EP

Quality Assurance

CE, RoHS, CSA, and EAC Marks
Made in an ISO 9001 and ISO 14001 compliant facility
UKCA Certified
E-Cell-3X Stacks are Halal certified by the Islamic Food and Nutrition Council of America (IFANCA®)

For more models, please visit: https://www.fgwater.com/Veolia-Electrodeionization-EDI-Stack-Module/389.html
